SL014972 With Size 360x480x118 mm Double Row Full Complement Cylindrical Roller Bearing
Overview
SL0149 series double row full complement cylindrical roller bearings are a locating bearing that can support axial forces in both directions as well as radial forces. The outer ring has ribs on both sides, is axially split, and held together by retaining rings. The inner ring has an additional central rib. The retaining rings must not be subjected to axial load.
Bore diameter-360 mm; Outside diameter-480 mm;Width-118 mm; Mass-62.1 kg;Cr=1790 kN;C0r=4450 kN;Limiting speed=730 1/min;Reference speed=350 1/min.
Interchangeable bearing code: NNC 4972 V
The related type: SL014972-A; SL014972-A-C3 Cylindrical roller bearings are also ready in stock for your machine application needs.
Specifications
| Part NO. | SL014972-Double Row Full Complement Cylindrical Roller Bearing |
| Brand | INA made in GERMANY and SDVV/ZBM brand made in China |
| Main Dimensions | 360x480x118 mm |
| d | 360 mm |
| D | 480 mm |
| B | 118 mm |
| rmin. | 3 mm |
| da | 404 mm |
| Da | 437 mm |
| C | 59 mm |
| Cr | 1790 kN |
| C0r | 4450 kN |
| Cur | 465 kN |
| Limiting speed | 730 1/min |
| Reference speed | 350 1/min |
| M | 62.1 kg |
