Available NU3188-M1 With Size 440x720x226 Single-Row Cylindrical Roller Bearing
Overview
Single row non-locating cylindrical roller bearings,With brass cage, In series NU, the outer ring has two ribs, while the inner ring has no ribs.M1-Two Piece Brass Cage Roller Guided;Running accuracy in P6. Operating temperature min.Tmin:-30 °C;Tmax. 150 °C.Normal radial internal clearance.
Bore diameter-440 mm;Outside diameter-720 mm;Width-226 mm; Mass-360.8 kg;Cr=5100 kN;C0r=9400 kN;Limiting speed=1330 1/min;Reference speed=390 1/min.
Extended similar type NU 3188 ECMA/HB1;NU3188-M1A;NU3188;NU3188-M1A are also In-stock for your more industrial solutions.
Specifications
| Dimensions &Technical Datasheets | |
| Part NO. | NU3188-M1 - Single-Row Cylindrical Roller Bearings |
| Brand | FAG brand made in GERMANY/SDVV brand made in China |
| Main Dimensions | 440x720x226 mm |
| d | 440 mm |
| D | 720 mm |
| B | 226 mm |
| rmin | 6 mm |
| Limiting speed | 1400 1/min |
| Reference speed | 450 1/min |
| da | 466 mm |
| Da | 694 mm |
| ra max. | 5 mm |
| Cr | 5100 kN |
| C0r | 9300 kN |
| M | 367 kg |
