30240-XL-DF-A550-600 With Size 200x360x116 mm Paired Tapered Roller Bearing Set
Overview
Paired double row tapered roller bearing set design; Normal (ISO 492:2014) tolerance class; Matched X arrangement. Can be used at operating temperatures from –30 °C to +200 °C.Sheet steel cage.
A550-600-Axial internal clearance between 550 and 600 µm
XL-X-life
Bore diameter-200 mm; Outside diameter-360 mm;Width-116 mm; Mass-52.9 kg;Cr=1540 kN;C0r=2120 kN;Cur=260 kN.
Could be interchangeable with 30240-A-DF-A550-600, 30240-A-N11CA-A550-600.
Specifications
| Dimensions &Technical Datasheets | |
| Part NO. | 30240-XL-DF-A550-600- Paired Tapered Roller Bearing Set |
| Brand | FAG made in GERMANY and SDVV/ZBM brand made in China |
| Main Dimensions | 200x360x116 mm |
| d | 200 mm |
| D | 360 mm |
| 2B | 116 mm |
| 2T | 128 mm |
| da max | 237 mm |
| Da max | 342 mm |
| r3, 4 min | 4 mm |
| Cr | 1540 kN |
| C0r | 2120 kN |
| Cur | 260 kN |
| M | 52.9 kg |
