NSK bearing catalog: NSK ball bearing, roller bearing, bearing units, Bearing accessories, linear bearings. NSK bearing catalogs give you the capability to select the correct NSK bearings that best meet the needs of your application and equipment design.

85BNR19HV1V

NSK Reference Models:

Bearing Numbers	d	D	B	r (min)	r1 (min)	Mass(kg) (approx)	Grease
30BNR19SV1V	30	47	9	0.3	0.15	0.048	36 400
30BNR19HV1V	30	47	9	0.3	0.15	0.043	46 800
30BNR19XV1V	30	47	9	0.3	0.15	0.043	54 600
30BER19SV1V	30	47	9	0.3	0.15	0.048	31 200
30BER19HV1V	30	47	9	0.3	0.15	0.043	41 600
30BER19XV1V	30	47	9	0.3	0.15	0.043	49 400
35BNR19SV1V	35	55	10	0.6	0.3	0.072	31 200
35BNR19HV1V	35	55	10	0.6	0.3	0.063	40 000
35BNR19XV1V	35	55	10	0.6	0.3	0.063	46 700
35BER19SV1V	35	55	10	0.6	0.3	0.072	26 700
35BER19HV1V	35	55	10	0.6	0.3	0.063	35 600
35BER19XV1V	35	55	10	0.6	0.3	0.063	42 300
40BNR19SV1V	40	62	12	0.6	0.3	0.105	27 500
40BNR19HV1V	40	62	12	0.6	0.3	0.092	35 300
40BNR19XV1V	40	62	12	0.6	0.3	0.092	41 200
40BER19SV1V	40	62	12	0.6	0.3	0.105	23 600
40BER19HV1V	40	62	12	0.6	0.3	0.092	31 400
40BER19XV1V	40	62	12	0.6	0.3	0.092	37 300
45BNR19SV1V	45	68	12	0.6	0.3	0.125	24 800
45BNR19HV1V	45	68	12	0.6	0.3	0.111	31 900
45BNR19XV1V	45	68	12	0.6	0.3	0.111	37 200
45BER19SV1V	45	68	12	0.6	0.3	0.125	21 300
45BER19HV1V	45	68	12	0.6	0.3	0.111	28 400
45BER19XV1V	45	68	12	0.6	0.3	0.111	33 700
50BNR19SV1V	50	72	12	0.6	0.3	0.127	23 000
50BNR19HV1V	50	72	12	0.6	0.3	0.111	29 600
50BNR19XV1V	50	72	12	0.6	0.3	0.111	34 500
50BER19SV1V	50	72	12	0.6	0.3	0.127	19 700
50BER19HV1V	50	72	12	0.6	0.3	0.111	26 300
50BER19XV1V	50	72	12	0.6	0.3	0.111	31 200
55BNR19SV1V	55	80	13	1	0.6	0.178	20 800
55BNR19HV1V	55	80	13	1	0.6	0.158	26 700
55BNR19XV1V	55	80	13	1	0.6	0.158	31 200
55BER19SV1V	55	80	13	1	0.6	0.178	17 800
55BER19HV1V	55	80	13	1	0.6	0.158	23 800
55BER19XV1V	55	80	13	1	0.6	0.158	28 200
60BNR19SV1V	60	85	13	1	0.6	0.19	19 400
60BNR19HV1V	60	85	13	1	0.6	0.17	24 900
60BNR19XV1V	60	85	13	1	0.6	0.17	29 000
60BER19SV1V	60	85	13	1	0.6	0.19	16 600
60BER19HV1V	60	85	13	1	0.6	0.17	22 100
60BER19XV1V	60	85	13	1	0.6	0.17	26 300
65BNR19SV1V	65	90	13	1	0.6	0.204	18 100
65BNR19HV1V	65	90	13	1	0.6	0.181	23 300
65BNR19XV1V	65	90	13	1	0.6	0.181	27 100
65BER19SV1V	65	90	13	1	0.6	0.204	15 500
65BER19HV1V	65	90	13	1	0.6	0.181	20 700
65BER19XV1V	65	90	13	1	0.6	0.181	24 600
70BNR19SV1V	70	100	16	1	0.6	0.328	16 500
70BNR19HV1V	70	100	16	1	0.6	0.292	21 200
70BNR19XV1V	70	100	16	1	0.6	0.292	24 800
70BER19SV1V	70	100	16	1	0.6	0.328	14 200
70BER19HV1V	70	100	16	1	0.6	0.292	18 900
70BER19XV1V	70	100	16	1	0.6	0.292	22 400
75BNR19SV1V	75	105	16	1	0.6	0.348	15 600
75BNR19HV1V	75	105	16	1	0.6	0.31	20 000
75BNR19XV1V	75	105	16	1	0.6	0.31	23 400
75BER19SV1V	75	105	16	1	0.6	0.348	13 400
75BER19HV1V	75	105	16	1	0.6	0.31	17 800
75BER19XV1V	75	105	16	1	0.6	0.31	21 200
80BNR19SV1V	80	110	16	1	0.6	0.366	14 800
80BNR19HV1V	80	110	16	1	0.6	0.326	19 000
80BNR19XV1V	80	110	16	1	0.6	0.326	22 200
80BER19SV1V	80	110	16	1	0.6	0.366	12 700
80BER19HV1V	80	110	16	1	0.6	0.326	16 900
80BER19XV1V	80	110	16	1	0.6	0.326	20 000
85BNR19SV1V	85	120	18	1.1	0.6	0.527	13 700
85BNR19HV1V	85	120	18	1.1	0.6	0.456	17 600
85BNR19XV1V	85	120	18	1.1	0.6	0.456	20 500
85BER19SV1V	85	120	18	1.1	0.6	0.527	11 800
85BER19HV1V	85	120	18	1.1	0.6	0.456	15 700
85BER19XV1V	85	120	18	1.1	0.6	0.456	18 600
90BNR19SV1V	90	125	18	1.1	0.6	0.552	13 100
90BNR19HV1V	90	125	18	1.1	0.6	0.48	16 800
90BNR19XV1V	90	125	18	1.1	0.6	0.48	19 600
90BER19SV1V	90	125	18	1.1	0.6	0.552	11 200
90BER19HV1V	90	125	18	1.1	0.6	0.48	14 900
90BER19XV1V	90	125	18	1.1	0.6	0.48	17 700
95BNR19SV1V	95	130	18	1.1	0.6	0.571	12 500
95BNR19HV1V	95	130	18	1.1	0.6	0.497	16 000
95BNR19XV1V	95	130	18	1.1	0.6	0.497	18 700
95BER19SV1V	95	130	18	1.1	0.6	0.571	10 700
95BER19HV1V	95	130	18	1.1	0.6	0.497	14 300
95BER19XV1V	95	130	18	1.1	0.6	0.497	16 900
100BNR19SV1V	100	140	20	1.1	0.6	0.77	11 700
100BNR19HV1V	100	140	20	1.1	0.6	0.673	15 000
100BNR19XV1V	100	140	20	1.1	0.6	0.673	17 500
100BER19SV1V	100	140	20	1.1	0.6	0.77	10 000
100BER19HV1V	100	140	20	1.1	0.6	0.673	13 400
100BER19XV1V	100	140	20	1.1	0.6	0.673	15 900

If you need help in selecting the best products for your particular application, please Contact us, thank you!
