7326 BGAM single row precision angular contact ball bearings130*280*58mm
Specifications and drawing for 7326 BGAM single row precision angular contact ball bearings
| d | 130 mm | Bore diameter |
| D | 280 mm | Outside diameter |
| B | 58 mm | Width |
| d1 | ≈189.9 mm | Shoulder diameter of inner ring (large side face) |
| d2 | ≈161.4 mm | Shoulder diameter of inner ring (small side face) |
| D1 | ≈227.5 mm | Shoulder diameter of outer ring (large side face) |
| a | 115 mm | Distance side face to pressure point |
| r1,2 | min.4 mm | Chamfer dimension |
| r3,4 | min.1.5 mm | Chamfer dimension |
| da | min.147 mm | Diameter of shaft abutment |
| Da | max.263 mm | Abutment diameter housing |
| Db | max.271 mm | Diameter of housing abutment |
| ra | max.3 mm | Radius of fillet |
| rb | max.1.5 mm | Radius of fillet |
| C | 276 kN | Basic dynamic load rating |
| C0 | 305 kN | Basic static load rating |
| Pu | 9 kN | Fatigue load limit |
| 2 800 r/min | Reference speed | |
| 3 400 r/min | Limiting speed | |
| A | 1.65 | Minimum axial load factor |
| kr | 0.09 | Minimum radial load factor |
| e | 1.14 | Limiting value |
Image of 7326 BGAM single row precision angular contact ball bearings
Application of 7326 BGAM single row precision angular contact ball bearings
Machine tool spindle, high-frequency motor, gas turbine, centrifugal separator, small car front wheel, differential pinion shaft, booster pump, drilling platform, food machinery, dividing head, repair welding machine, low-noise cooling tower, electromechanical equipment, coating equipment, machine tool slot plate, arc welding machine.
If you want to know more about 7326 BGAM bearing, or any other bearing you are looking for. You can send me inquiry below
