Specifications:
Inside Diameter (mm):10
Outside Diameter (mm):26
Width (mm):8
Contact Angle:15°
Rows Of Balls: Single row
Seal: open
Ring: Chrome Steel
Roller: Chrome Steel
Cage Material: Phenolic Resin
Weight: 0,020 Kg
Extended spindle bearings:
| Model: | D | B | C | r(min) | r1(min) | ra(max) | contact angle | Weight(KG) |
| B7000-C-T-P4S-UL | 26 | 8 | 6.4 | 0.3 | 0.3 | 0.3 | 15° | 0.02 |
| B7001-C-T-P4S-UL | 28 | 8 | 6.7 | 0.3 | 0.3 | 0.3 | 15° | 0.021 |
| B7002-C-T-P4S-UL | 32 | 9 | 7.6 | 0.3 | 0.2 | 0.3 | 15° | 0.028 |
| B7003-C-T-P4S-UL | 35 | 10 | 8.5 | 0.4 | 0.3 | 0.3 | 15° | 0.039 |
| B7004-C-T-P4S-UL | 42 | 12 | 10.2 | 0.6 | 0.3 | 0.6 | 15° | 0.067 |
| B7005-C-T-P4S-UL | 47 | 12 | 10.8 | 0.6 | 0.3 | 0.6 | 15° | 0.075 |
| B7006-C-T-P4S-UL | 55 | 13 | 12.3 | 1 | 0.6 | 1 | 15° | 0.108 |
| B7007-C-T-P4S-UL | 62 | 14 | 13.5 | 1 | 0.6 | 1 | 15° | 0.153 |
| B7008-C-T-P4S-UL | 68 | 15 | 14.7 | 1 | 0.6 | 1 | 15° | 0.188 |
| B7009-C-T-P4S-UL | 75 | 16 | 16 | 1 | 0.6 | 1 | 15° | 0.239 |
| B7010-C-T-P4S-UL | 80 | 16 | 16.7 | 1 | 0.6 | 1 | 15° | 0.254 |
| B7011-C-T-P4S-UL | 90 | 18 | 18.7 | 1.1 | 0.6 | 1 | 15° | 0.377 |
| B7012-C-T-P4S-UL | 95 | 18 | 19.4 | 1.1 | 0.6 | 1 | 15° | 0.401 |
| B7013-C-T-P4S-UL | 100 | 18 | 20.1 | 1.1 | 0.6 | 1 | 15° | 0.426 |
| B7014-C-T-P4S-UL | 110 | 20 | 22.1 | 1.1 | 0.6 | 1 | 15° | 0.577 |
| B7015-C-T-P4S-UL | 115 | 20 | 22.9 | 1.1 | 0.6 | 1 | 15° | 0.608 |
| B7016-C-T-P4S-UL | 125 | 22 | 24.7 | 1.1 | 0.6 | 1 | 15° | 0.836 |
| B7017-C-T-P4S-UL | 130 | 22 | 25.4 | 1.1 | 0.6 | 1 | 15° | 0.878 |
| B7018-C-T-P4S-UL | 140 | 24 | 27.4 | 1.5 | 0.6 | 1.5 | 15° | 1.13 |
If you need more information, please contact WhatsApp: +86 13520524683 |
